Belt Drives

X1 Pro & X1 Stealth

The X1 Pro and X1 Stealth kits run a standard 104BCD inner chainring so you can easily swap it out with a belt drive compatible chainring. The belt width is not recommended to be more than 15mm.

• Gates and Veer compatible
• Please note that only chainring driving the cassette can be swapped to a belt drive. The 219H motor chainring cannot be swapped.

More examples can be found here: Belt Drive Setups

Photon

Belt drive systems are currently not compatible with the Photon as the chainring fitment is not standard. However, we have started testing this for future development, particular with Veer. Please let us know if you'd like to be added to the notification list.
